Single-frame Precision
Up to 0.05mm
Working Distance
150mm - 400mm
Point Distance
0.05mm
Auxiliary IR & White LEDs
For Enhanced 3D Scanning
POP 3 has a brand-new design for enhanced color capture, better tracking, and usability.
Time-Saving Accuracy
Eliminate the need to manually measure objects by consistently and efficiently capturing accurate and detailed 3D models at fast scanning speeds between 12 to 18fps with a single-frame precision of up to 0.05mm and 0.05mm point distance.
Enhanced Marker Tracking
Experience accurate, reliable, and efficient marker tracking scans and scanner calibration thanks to the four powerful infrared LEDs enhancing marker visibility.
Precision in Motion
Enjoy a seamless tracking and frame stitching experience with POP 3’s 9-axis IMU (Inertial Measurement Unit) continuously measuring the scanner’s movement. At the same time, an advanced algorithm eliminates faulty frames caused by sudden movement or shaking.
Single Capture Range
225mm x 125mm
Scanning Speed
12fps - 18fps
Touch Button
Controls
Connection Port
Type-C
High Fidelity Color Scans
Improved color scanning with the RGB camera’s 30% larger aperture letting more light reach the sensor. And dual white LEDs illuminate and remove shadows from the scanned object, so POP 3 can capture more vibrant and lifelike full-color 3D scans.
Streamlined Controls
POP 3’s new design is built around optimizing the scanning experience. With the addition of three touch-sensitive buttons to Start/Pause scans and adjust the depth camera's exposure on the fly.
Energized Connectivity
Powered by Wi-Fi 6, POP 3 can transfer data nearly three times faster than POP 2 for lower latency and smoother mobile scanning. And a new Type-C USB connector for compatibility with your other cables and faster to set up.
Unlock 3D Printing
With POP 3
Quickly and easily create accurate ready-to-print 3D models of nearly any object without building it from scratch in time-consuming 3D modeling software.
- Standard
- Advanced
Advanced Package Accessories
Dual-axis Turntable
Simplify the scanning process and eliminates the need for object repositioning during scanning with the Dual-axis Turntable's adjustable speed rotation, ±30° tilt, and 5kg max load. Easily control it in Revo Scan or Revo Assistant.
Buy Now
Handheld Power Bank
Clip this handy Handheld Power Bank onto the bottom of your POP 3 for up to 4 hours of conveniently powered mobile scanning.
Buy NowAdvanced Package Accessories
Dual-axis Turntable
Simplify the scanning process and eliminates the need for object repositioning during scanning with the Dual-axis Turntable's adjustable speed rotation, ±30° tilt, and 5kg max load. Easily control it in Revo Scan or Revo Assistant.
Buy Now
Handheld Power Bank
Clip this handy Handheld Power Bank onto the bottom of your POP 3 for up to 4 hours of conveniently powered mobile scanning.
Buy NowThe Buzz on POP 3
Specifications
| Product Name | Revopoint POP 3 | Point Distance/Resolution | Minimum 0.05mm |
| Technology | Dual Camera Infrared Light | Special Object Scanning | Use scanning spray and the correct scanning mode for transparent, dark, or highly reflective objects. |
| Single-frame Precision | Up to 0.05mm | Scanning Environment | Indoors and Outdoors |
| Single-frame Accuracy | Up to 0.1mm | Scanner Weight | 190g |
| Single Capture Range | 225mm x 125mm | Scanner Dimensions | 153mm x 29mm x 45mm |
| Working Distance | 150mm ~ 400mm | 3D Printing Compatible | Yes |
| Minimum Scan Volume | 20mm x 20mm x 20mm | Compatible OS | Windows 10/11 (64-bit), Android, iOS, macOS |
| Scanning Speed | 12 - 18fps | Auxiliary Lighting | 4 IR LEDs / 2 White LEDs |
| IMU | 9-axis | Lumens | White LEDs: 110 ~ 130 |
| Light Source | Class 1 Infrared Light | Color Temperature | White LEDs: 6000k ~ 6500K |
| Alignment Modes | Feature/Marker | Connection Modes | Type-C USB 3.0 |
| Color Scanning | Yes | External Controls | 3 Touch-sensitive Buttons |
| Output Formats | PLY, OBJ, and STL | Wi-Fi | 6.0 |
