INSPIRE is our most cost-effective 3D scanner. It's compact yet packed with advanced 3D scanning technology designed to create a user-friendly capturing experience for 3D printing enthusiasts, makers, and designers.
Revopoint INSPIRE: User-friendly Cost-effective 3D Scanner for 3D Printing
· 14 to 18 fps Scanning Speeds
· Up to 0.1 mm Point Distance
· Weighs Only 140 g
· Stable Scanning With 9-axis IMU
Free shipping for most countries, 3-5 days fast receipt.
Delivery time deviates according to the effectiveness of the transport company, please wait patiently for your goods
Up to 4 installments with 0 interest.
Once payment has been made, the statement reflected in your bank account will be reverted to your local currency
14-day no-hassle returns, 30-day free exchange, 2-year warranty.
24/7 online customer support.
Handheld or turntable scanning
Connects to Android and iOS devices
Easy Object Capture
230 mm x 140 mm single capture area for easy tracking
Marker-free object scanning
Dual Infrared LEDs
Enhanced Marker Tracking
3D Models Made With INSPIRE
What’s in the Box?
Accessories for Enhanced Scanning
Everything needed for convenient mobile scanning.
Fast adjustable rotation speeds and ±30° tilt for easy object capture.
Use to scan transparent, highly reflective, or dark objects.
Rechargeable Mini LED Light
A portable LED soft lighting system for improved color scans.
Which Scanner is RIGHT for you?
|Hide the same parameters|
|Scanning Type||Handheld and Turntable||Handheld and Turntable||Handheld and Turntable||Handheld and Turntable|
|Technology||Dual-Camera Infrared Structured Light||Dual-camera Infrared Structured Light||Dual-camera Infrared Structured Light||Dual-camera Blue Structured Light|
|Single-frame Precision, up to||0.1 mm||0.05 mm||0.1 mm||0.02 mm|
|Single-frame Accuracy, up to||0.2 mm||0.1 mm||0.3 mm||0.05 mm|
|Point Distance (Resolution), up to||0.1 mm||0.05 mm||0.1 mm||0.02 mm|
|Working Distance||250 ~ 500 mm||150 ~ 400 mm||300~ 800 mm||100~ 200 mm|
|Closest Single Capture Range||162 x 111 @250 mm||61 x 68 @150 mm||130 x 310 @300 mm||40 x 50 @100 mm|
|Furthest Single Capture Range||308 x 225 @500 mm||244 x180 @ 400 mm||396 x 831@ 800 mm||118 x 100 @ 200 mm|
|Angular Field of View, H x W||40 x 25°||40 x 25°||36 x 55°||37 x 28°|
|Minimum Scan Volume||50 x 50 x 50 mm||20 x 20 x 20mm||50 x 50 x 50 mm||10 x 10 x 10 mm|
|Maximum Scan Volume||2000 x 2000 x 2000 mm||2500 x 2500 x 2500 mm||4000 x 4000 x 4000 mm||500 x 500 x 500 mm|
|Scanning Speed||14 - 18 fps||12 - 18 fps||12 - 18 fps||Up to 10 fps|
|Depth Camera Resolution, up to||1 Megapixels||1 Megapixels||1 Megapixels||1 Megapixels|
|RGB Camera Resolution||1 Megapixels||1 Megapixels||1 Megapixels||1 Megapixels|
|Tracking Methods||Feature, Marker||Feature, Marker||Feature, Marker||Feature, Marker|
|3D Light Source||Class 1 Infrared Light||Class 1 Infrared Light||Class 1 Infrared Light||Class 1 Blue Light|
|White LED Flash||Yes||Yes||No||No|
|Infrared Fill Lights||Yes||Yes||No||No|
|Positioning Sensors||9-axis IMU||9-axis IMU||No||No|
|CPU||2 core, 1.6 GHz||2 core, 1.6 GHz||2 core, 1.6 GHz||2 core, 1.6 GHz|
|Internal Processing||Depth map computing||Depth map computing||Depth map computing||Depth map computing|
|Minimum System Requirements||Intel Core i5, 8 GB RAM||Intel Core i5, 8 GB RAM||Intel Core i5, 8 GB RAM||Intel Core i5, 8 GB RAM|
|Recommended System Requirements||Intel Core i7, 16 GB RAM or better||Intel Core i7, 16 GB RAM or better||Intel Core i7, 16 GB RAM or better||Intel Core i7, 16 GB RAM or better|
|Compatible Systems||Windows 10/11, Android, iOS, macOS||Window 10/11 (64-bit), Android, iOS, macOS||Windows 10/11 (64-bit), Android, iOS, macOS||Windows 10/11 (64-bit), Android, iOS, macOS|
|STL, PLY, & OBJ||STL, PLY, & OBJ||STL, PLY, & OBJ||STL, PLY, & OBJ||STL, PLY, & OBJ|
|Ready to Print 3D Models||✔||✔||✔||✔|
|Connector Type||USB Type-C||USB Type-C||USB Micro-B||USB Micro-B|
|Power Requirements||DC 5V, 1A||DC 5V, 1A||DC 5V, 1A||DC 5V, 1A|
|Dimensions L x W x H||132 x 45 x 27 mm||153 x 45 x 29 mm||295 x 42 x 28.2mm||120 x 39 x 25mm|
|Special Object Scanning||Use scanning spray for transparent, dark, or highly reflective objects.||Use scanning spray for transparent, dark, or highly reflective objects.||Use scanning spray for transparent, dark, or highly reflective objects.||Use scanning spray for transparent, dark, or highly reflective objects.|
What are the differences between POP 3, MINI, RANGE, and INSPIRE?
● Scanning Scenarios The INSPIRE is for hobbyists, 3D printing enthusiasts, and makers who want to scan medium-sized objects.
The RANGE is designed for professionals who want to scan large objects such as furniture, human bodies, and vehicles, ensuring efficient and thorough scanning results.
The MINI is designed for professionals who want to scan smaller objects such as jewelry, miniature figurines, or hardware components, providing precise detail-capturing capabilities.
The POP 3 is designed for professionals who want to scan medium-sized objects, such as engine parts or vases.
Recommend Scan Volumes:
MINI: 10 mm × 10 mm × 10 mm - 500 mm × 500 mm × 500 mm.
POP 3: 20 mm × 20 mm × 20 mm - 2500 mm × 2500 mm × 2500 mm.
RANGE: 50 mm × 50 mm × 50 mm - 4000 mm × 4000 mm × 4000 mm.
INSPIRE: 50 mm × 50 mm × 50 mm - 2000 mm × 2000 mm × 2000 mm.
What’s special about INSPIRE’s IMU?
INSPIRE’s IMU is a 9-axis IMU with a gyroscope, accelerometer, and magnetometer that all work together to help INSPIRE understand its location as you move the scanner around an object. This, in turn, helps INSPIRE to provide smoother frame stitching as well as helping to eliminate any faulty frames captured caused by shaking or moving too fast.
What is Magic Mat?
Magic Mat is a 50 cm × 50 cm black mat with highly reflective marker points across its surface that is designed to make scanning featureless objects much easier by removing the need to place marker points on the item.
Do you need a powerful computer to use the INSPIRE?
No, the INSPIRE’s algorithms and internal chip do most of the processing.
Minimum specs: Intel i5, 8GB RAM.
Recommended specs: Intel i7, 16GB RAM.
No discrete GPU like an Nvidia or AMD graphics card is needed to use INSPIRE.
Does INSPIRE have 3D scanning software?
Yes, the INSPIRE comes with Revo Scan for free. It is compatible with iOS, macOS, Android, and Windows devices. In Revo Scan, you can perform scans and post-processing.
Is third-party scanning software available for INSPIRE?
No, INSPIRE is only compatible with the Revo Scan software, which you can download from our website or your device's app store. However, the models generated by the scan are compatible with nearly all third-party 3D modeling software.
What are marker points used for?
Marker points are stuck on or around objects without geometric features so the INSPIRE can track what it is scanning. When using Marker points, place them in irregular patterns with around 3-5 cm between the markers across the object you’re scanning, and ensure that there are 5 marker points always in the frame when scanning.
How do I use the Mini Turntable?
Connect the Mini turntable to either your computer or a plug to power it, then use the controls on the Mini turntable’s side.
Do more frames scanned mean better 3D scan accuracy?
No, repeated scanning makes your model worse. One scan close to the object will result in the best accuracy.
Can I use the INSPIRE outdoors?
Yes, but it will not work well in direct sunlight. The INSPIRE is not water resistant, so avoid outdoor scanning on rainy days.
